Product name Resisto 1200 IP66 2800lm 830 Technology LED Housing PC Polycarbonate General application Logistics & Industry Operating temperature range (°C) -20°C - 40°C Performance ambient temperature Tq (°C) 25 ETIM Class EC002892 E-number FI 4357040 Warranty 5 years Optical data Fixture luminous flux (lm) 2800 Luminaire efficacy (lm/W) 133 Colour temperature (K) 3000 CRI (Ra) 80 Colour Variation Initial (SDCM) SDCM5 Colour Consistency (SDCM) 5 Beam Angle (°) 110 Distribution type Diffuse Glare control < 22 Photobiological Risk Group RG1 Electrical data Total power consumption (W) 21 Mains voltage (V) 220-240V~ Lamp power factor 0.95 THD (at 230 V, 50 Hz, full load, at 100% dimming level) ? xx.x % 20 Electrical protection Class I No. Of switching cycles before premature failures >50000 Dimmable No Drive current (mA) 350 Inrush Current (A) 6.1 Inrush Duration (µs) 18 Glow Wire Test (°C) 850 Nominal Frequency (Hz) 50/60Hz LED Flickering Rate Ultra low (5% or less) Max. Luminaires per 10A C Breaker 60 Max. Luminaires per 13A C Breaker 79 Max. Luminaires per 16A C Breaker 97 Max. Luminaires per 20A C Breaker 121 Max. Luminaires per 10A B Breaker 60 Max. Luminaires per 13A B Breaker 79 Max. Luminaires per 16A B Breaker 97 Max. Luminaires per 20A B Breaker 121 Lifetime data Lifespan L70 B50 100000 Lifespan L80 B20 69000 Lifespan L90 B10 31000 Physical data Housing colour Grey IP rating IP66 IK rating IK08 Diffuser finish Frosted Diffuser material PC Polycarbonate Nominal Product Length (mm) 1200 Nominal Product Width (mm) 87 Nominal Product Height (mm) 80 Weight (kg) 1.5
