| Gyártói cikkszám: | 28002467 |
| Szín: | FEHÉR |
| Cikkszám: | TME-28002467 |
| Megnevezés teljes név: | LED tápegység impulzusos LC 71W 250-350ma flexc lp adv tridoc |
Technical data Rated supply voltage 220 – 240 V AC voltage range 198 – 264 V DC voltage range 176 – 280 V Max. input current (at 230 V, 50 Hz, full load) 0.36 A Typ. input current (at 230 V, 0 Hz, full load) 0.36 A Leakage current (at 230 V, 50 Hz, full load) < 450 µA Mains frequency 0 / 50 / 60 Hz Overvoltage protection 320 V AC, 48 h Max. input power 77.9 W Typ. power consumption (at 230 V, 50 Hz, full load) 77.6 W Min. output power 23.3 W Max. output power 71 W Typ. efficiency (at 230 V / 50 Hz / full load)1 91.5 % ? (at 230 V, 50 Hz, full load)1 0.95 Output current tolerance2 ± 7.5 % Max. output current peak3 ? output current + 10 % Max. output voltage 250 V THD (at 230 V, 50 Hz, full load) < 20 % Output LF current ripple (< 120 Hz) ± 5 % Starting time (at 230 V, 50 Hz, full load) < 500 ms Starting time (DC mode) < 1,000 ms Switchover time (AC/DC)5 < 500 ms Turn off time (at 230 V, 50 Hz, full load) ? 0.5 s Hold on time at power failure (output) 0 s Ambient temperature ta (at life-time 100,000 h) 40 °C Storage temperature ts -40 ... +80 °C Life-time up to 100,000 h Dimensions L x W x H 280 x 30 x 21 mm Hole spacing D 268 mm
termék hozzáadva a kosárhoz
Nincs készleten
