Ratings per IEC/EN 60947-7-1
Nominal voltage (III/3) 800 V
Rated surge voltage (III/3) 8 kV
Rated current 32 A
Rated current 2 41 A
Legend (ratings) (III / 3) ? Overvoltage category III / Pollution degree 3
More
Ratings per UL
Approvals per UL 1059
Rated voltage UL (Use Group B) 600 V
Rated current UL (Use Group B) 30 A
Rated voltage UL (Use Group C) 600 V
Rated current UL (Use Group C) 30 A
Ratings per CSA
Approvals per C22.2 No 158
Rated voltage CSA (Use Group B) 600 V
Rated current CSA (Use Group B) 30 A
Rated voltage CSA (Use Group C) 600 V
Rated current CSA (Use Group C) 30 A
Ex information
Ratings per ATEX: PTB 05 ATEX 1095 U / IECEx: PTB 05.0033U (Ex eb IIC Gb)
Rated voltage EN (Ex e II) 550 V
Rated current (Ex e II) 30 A
Connection data
Connection technology Push-in CAGE CLAMP®
Actuation type Push-in
Open Tool Slot
Connectable conductor materials Copper
Nominal cross-section 4 mm2
Solid conductor 0.5 … 6 mm2 / 20 … 10 AWG
Solid conductor; push-in termination 1.5 … 6 mm2 / 14 … 10 AWG
Fine-stranded conductor 0.5 … 6 mm2 / 20 … 10 AWG
Fine-stranded conductor; with insulated ferrule 0.5 … 4 mm2 / 20 … 12 AWG
Fine-stranded conductor; with ferrule; push-in termination 1.5 … 4 mm2 / 18 … 12 AWG
Note (conductor cross-section) Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
Strip length 11 … 13 mm / 0.43 … 0.51 inch
Total number of connection points 2
Total number of potentials 1
Number of levels 1
Wiring direction Front-entry wiring
Number of jumper slots 2
